Dual Audio-Video Balun
【M-DAVB】
Audio up to 3,250 ft (1,000m) via Cat5e/6
20 Hz to 20 kHz audio bandwidth
Cost-efficient cabling
Quicker moves, adds and changes
Overview
The Dual Audio-Video Balun(MB-DAVB) allows up to two
composite video signals and up to two
unbalanced audio signals to be transmitted via
unshielded twisted pair (UTP) cable in a point-to-point
connection.Used in pairs, the Dual Audio-Video Balun,
allowing audio-video equipment to be connected via
space-efficient and cost-effective Cat5e/6 twisted
pair cable for commercial and residential hi-definition
(HDTV) video applications and so on
Applications
classroom video distribution,
commercial and home audio/video
systems, hospital video training, video
conferencing, and video kiosks
Features & Benefits
Video up to 2,200 feet (670m) via Cat5e/6
Audio up to 3,250 ft (1,000m) via Cat5e/6
20 Hz to 20 kHz audio bandwidth
Cost-efficient cabling
Quicker moves, adds and changes
Quick Setup Guide:
Plug the RCA connectors of the transmit Balun into the Video and Audio
outputs of the source component you wish to transmit. Plug the Video and
Audio connectors from the receive Balun into your desired input component.
Insert the CAT5 cable into both ends of the Baluns. You may use standard
EIA 568A/B termination.
Typical Application
Specifications:
|
Environment |
Composite video (NTSC, PAL, SECAM).and Stereo HI-FI audio. | |
|
Devices |
DVD players, VCR, satellite receivers, MPEG players, laptops, notebooks,monitors, DLP projectors, CCD cameras, video switchers, sequencers, digital video servers, video multiplexers, video splitters, video converters and other composite video equipment. | |
|
Transmission |
Transparent to the user. | |
|
Composite video |
audio | |
|
Bandwidth |
Video: 60 MHz, 3 dB roll off |
20 Hz to 20 KHz over the distance range |
|
Maximum Input |
1.1Vp-p |
1.1Vp-p |
|
Impedance |
75 ohms |
600 ohms min |
|
Insertion Loss |
Less than 2 dB per pair over the frequency range from DC to 6 MHz |
Less than 2 dB per pair over the frequency range |
|
Return Loss |
Better than 15 dB over the frequency range |
Better than 15 dB over the frequency range |
|
Common Mode Rejection Ratio |
Greater than 40 dB over the frequency range |
Greater than 40 dB over the frequency range |
|
Max. Distance Color via Cat 5E/6 UTP/STP Cable |
2,200 ft (670 m) |
3,250 ft (1,000 m) |
|
Pin Configuration (RJ45) |
Video: Pins 4(R) &5(T) Video: Pins 7(R) &8(T) |
Audio 1: Pins 1(R) & 2(T) Audio 2: Pins 3(R) & 6(T) |
|
Cable: Cat 5E/6 UTP/STP |
24 AWG or lower solid copper twisted pair wire Impedance: 100 ohms at 1 MHz Maximum capacitance: 20 pf/ft Attenuation: 6.6 dB/1,000 ft at 1 MHz | |
|
Connectors |
Three RCA-F connectors: Video (yellow) & stereo audio (red, white) One RJ45 for Cat 5E/6 | |
|
Temperature |
Operating: 0° to 55°C Storage: -20° to 85°C Humidity: Up to 95% non-condensing | |
|
Enclosure |
Aluminum alloy | |
|
Dimensions(packaging) |
155mm*80mm*30mm (including one pair of Balun) | |
|
Weight(packaging) |
260g | |
NOTE: Baluns are interchangeable for transmit or receive functions.
